2led Modules for Signs
2led modules for signs and light box,IP65 waterproof can use for indoor and outdoor.
Parameter
|
Model: |
4015 led injection module |
|
Chip: |
SMD2835 |
|
Size: |
40*15mm |
|
Colors: |
White,Red,Blue,Green,Yellow,Pink,Purple |
|
Power（W）: |
1.5Watts |
|
Voltage: |
DC12V |
|
Color Temperature: |
3000-20000K |
|
Lumen/module: |
150ML |
|
Operation temperature: |
-25°C~60°C |
|
IP Rate: |
IP65 |
|
Beam Angle: |
160°degree |
|
Certification: |
CE and ROHS |
|
Life time: |
20,000hrs |
|
Warranty: |
3 Years |
|
Dimmable: |
No |
|
Weight(KG): |
0.005kg |
|
Material: |
Aluminum PCB+PVC |
|
Country of origin: |
China |
|
Usage: |
Channel Letter.light Box.backlight,signage |
Feature
|
·Low energy consumption: same brightness, lower power consumption and heat production than similar products; |
|
·High quality PVC injection molding process, beautiful appearance, good heat dissipation |
|
·CE and ROHS certification |
|
·Sanan chip, optical diffuse lens |
|
·Ultra-high brightness, optimal price, more than 3 years of quality assurance |
|
·DC12V low voltage input, waterproof IP65 for indoor and outdoor signage, light box |
Applications
2led modules for signs， Billboard, Signage and illuminated advertising, As the Backlighting of channel letters and light box.
Package
Every 20 pcs per a string, every 10 string inan anti-static bag, 4000 pcs per a carton box. Carton size: 58*30*30 cm.
Net Weight: 5 g/pcs; 100 g/string; 20kg/carton.
Installation methods
Double-sided adhesive pre-fixed, screw hole screw fixed;
Warranty
3 yea20000 hours, whichever comes first
Delivery
1. By express(EMS,UPS,DHL,TNT,FEDEX and ect).5-7days
2. By air,10-15days
3. By sea,30-50days
4. By train,30-40days
LED Module FAQ
1.How long after payment will the goods be delivered?
-3-5 days for regular products, 7-10 days for custom products
2.What are the advantages of your product?
-Big factory, fast delivery, good quality, can be customized, the selection of big brand raw materials,
